BORETTI CFBG902AN - Page 223

223
Internal cylindrical thread ISO 7-1
Apply a sealing product
External cylindrical thread ISO 228-1 External cylindrical thread ISO 228-1
Flexible metal pipes
AGB / BGV
Sealed joint Internal cylindrical thread ISO 228-1 External cylindrical thread ISO 228-1 Thread ISO 7-1 Gas supply pipes
AGB-BGV authorised gas stop cock
Linking
component
Loose nut Loose nut
Gas appliance
External conical thread ISO 7-1 Sealed joint
Internal cylindrical thread ISO 228-1 Sealed joint
AGB / BGV
Flexible elastomer
Sealed joint Internal cylindrical thread ISO 228-1 External cylindrical thread ISO 228-1 Thread ISO 7-1 Gas supply pipes
AGB-BGV authorised gas stop cock
Loose nut Loose nut
Gas appliance
External cylindrical thread ISO 228-1
A new flexible AGB-BGV elastomer hose in the two versions to be assembled.
Gas appliance
External cylindrical thread ISO 228-1
Apply a sealing product
External conical thread ISO 7-1
Internal cylindrical thread ISO 7-1 Internal cylindrical thread ISO 228-1
Internal cylindrical thread ISO 228-1 Sealed joint
Conical
surface
Conical surface
Flexible metal pipes
AGB / BGV
Internal cylindrical thread ISO 7-1 Thread ISO 7-1
AGB-BGV authorised gas stop cock
Loose nut
Apply a sealing product
Gas supply pipes
Covering in a synthetic material
Stainless steel braiding
Stainless steel flexible pipe
Seal: for metal to metal contact Spherical surface Internal cylindrical thread ISO 228-1 External conical thread ISO 7-1 ISO 7-1
Flexible metal R
HT
pipe, AGB-BGV certificated
Gas appliance
Fig. 9.5
Fig. 9.6
