Borg & Overstrom b4 - CO2 Bottle Installation

B4.2 Install & Operation ManualBorg & Overström AU9
5
COLD
CO2 Bottle Installation (Sparkling Versions Only)
IMPORTANT! ALWAYS ENSURE SECURITY CLIPS ARE USED
ON ALL WATER AND CO2 CONNECTIONS.
OFF
10 L
1
hour
Attach the regulator to the disposable
CO2 bottle, ensuring the regulator is
closed.
Connect the assembled CO2 bottle and
regulator to the machine using 1/4 inch
pipe.
After completing the water installation,
turn on the sparkling power switch and
the pump will run. Do not open the
regulator valve until the carbonated
switch has been turned on.
Flush through approximately 10 litres of
sparkling water. Check and adjust the
CO2 pressure accordingly.
Following installation, it will be necessary
to leave the machine for up to 1 hour for
the initial chilling cycle to occur.
1 2
3
6
We recommend between 3.5 - 4 bar.
Do not exceed 4 bar pressure.
4 Max
bar
4
