Mounng the addional handle (Fig. H, I)
• Place the underside of the addional handle (13) on the upper telescopic rod (4).
• Insert the handle (G) of the addional handle into the handle holder (H).
• Insert the mounng screw (I) through the large hole on the addional handle and ghten it clockwise unl the posion of the addional handle is xed.
Cauon: Always use the addional handle while operang the machine. Risk of injury.
Mounng the guide wheel
The guide wheel can be aached in two dierent posions, depending on the task at hand.
- Proceed as follows if you want to use the machine to trim areas (Fig. J)
• Mount the guide wheel (15) on the safety guard (9) by sliding the guide wheel onto the provided metal plate (J). Ensure that the guide wheel snaps into place.
- Proceed as follows if you want to use the machine to trim edges (Fig. K)
• Mount the guide wheel (15) on the motor unit (12) by sliding the guide wheel onto the provided metal plate. Ensure that the guide wheel snaps into place.
Note: To avoid damaging the machine, be careful not to apply excessive pressure on the guide wheel.
Switching on/o (Fig. L)
- Switching on
• Hold the product rmly with both hands using the handle (1) and the addional handle (13).
• Press the safety lock (2) on the side of the handle.
• Press and hold the ON/OFF switch (3).
- You can release the safety lock keeping the on/o switch pressed.
- Switching o
• Release the ON/OFF switch.
Operaon
Aligning the cung head (Fig. M)
The motor unit can be locked in 2 dierent posions.
• Hold the motor unit (12) with one hand and with the other the lower telescopic rod (7).
• Pull the lower telescopic rod away from the motor unit and turn the motor unit to the desired posion.
• Let go of the motor unit and make sure that it clicks back into place in the desired posion to prevent the posion from changing unintenonally.
Adjusng the cung angle (Fig. N)
Using the adjustment buon (8) you can lock the cung angle in 5 posions between 0° and 90°.
• Place the machine rmly on the ground and push the lt angle adjustment buon on both sides.
• Release the adjustment buon to x the adjusted lt angle.
• Make sure that the adjustment buon and the motor unit (12) audibly click into place.
Warning: Ensure that the cung head is xed properly before operang the machine.
Adjusng the addional handle (Fig. O)
To improve user comfort, the addional handle (13) can be adjusted. Proceed as follows:
• Loosen the mounng screw (H) unl it can be easily moved along the handle.
• You can also adjust the lng angle of the addional handle by loosening the mounng screw unl the lng angle can be adjusted without much resistance.
• Fix the addional handle in place by ghtening the fastening screw again.
Warning: Ensure that the front handle is xed properly before operang the machine.
Adjusng the telescopic extension (Fig. P)
In order to adjust the length of the telescopic rod, proceed as follows:
• Loosen the lock nut (6).
• Pull the telescopic rod (7) as far as necessary from the upper telescopic rod (5).
• Fix the telescopic rod at the desired length by ghtening the lock nut again.
Warning: Ensure that the telescopic rod and its connecng points are xed properly before operang the machine.
• Turn the machine over so that the cung head (10) is at the top.
• Press the two locking buons (D) on the cung head simultaneously and remove the cover.
• Place the thread spool (16) on the guide axis in the housing.
• Insert the thread end through the thread outlet hole (E).
• Replace the cover.
• Make sure that the cover ts exactly into the grooves on the cung head and that it audibly clicks into place.
• Press the lock buon (F) on the outside of the cung head and pull out the thread end so that it is level with the thread cuer.
Inserng/replacing thread spool (Fig. E, F, G)
