BorMann Pro BDC2000 - Technical Specifications; Measurement Ranges and Accuracy

EN
WWW.BORMANNTOOLS.COM
4
AC VOLTAGE (Auto ranging)
TEMPERATURE DC CURRENT
DC VOLTAGE (Auto ranging)
Range Resoluon Accuracy
600mV 0.1mV ±(0.8% of rdg + 5dgts)
6V 1mV
±(0.8% of rdg + 3dgts)60V 10mV
600V 100mV
1000V 1V ±(1.0% of rdg + 5dgts)
Range Resoluon Accuracy
600mV 0.1mV ±(1.2% of rdg + 8dgts)
6V 1mV
±(1.2% of rdg + 6dgts)60V 10mV
600V 100mV
750V 1V ±(1.2% of rdg + 8dgts)
Range Resoluon Accuracy
600µA 0.1µA
±(0.8% of rdg + 5dgts)
6000µA 1µA
60mA 10µA
600mA 100µA
6A 1mA
±(1.5% of rdg + 3dgts)
10A 10mA
Range Resoluon
Accuracy
-40 ~
1°C
-40°C~150°C:±(1% + 4)
1370°C 150°C~1370°C:±(2% + 3)
-40 ~
1°F
-40°F~302°F:±(5% + 4)
2000°F 302°F~2000°F:±(2.5% + 3)
Input Impedance: 10MΩ
Overload Protecon: 600V DC/AC RMS
Max. Input voltage: 600V DC
Measure DVC 1000V under CATII
1. Input Impedance: 10MΩ
2. Frequency Range: 40Hz ~ 400Hz
3. Overload Protecon: 600V DC/AC rms
Measure ACV 750V under CATII CAT III
Max. Input voltage: 600V AC RMS CATIII
1. Input Impedance: 10MΩ
2. Frequency Range: 40Hz ~ 400Hz
3. Overload Protecon: 600V DC/AC rms
Measure ACV 750V under CATII CAT III
Max. Input voltage: 600V AC RMS CATIII
1. Overload Protecon: “mA” jack: F0.4A/600V fuse
“10A” jack: F10A/600V fuse
2. Max.Input Current:“mA” jack: 600mA, “10A” jack: 10A
(For measurements>5A: duraon <10 seconds, interval >15 minutes)
3. Voltage Drop: 600µA, 60mA: 60mV, 6000µA, 600mA and 10A ranges:
600mV
Overload Protecon: F0.4A/600V Fuse
Technical Data
DCV 60m-600m-6-60-600V ±0.5%
ACV 60m-600m-6-60-600V ±1.0%
DCA 600u-6000u-60m-600m-10A ±1.8%
ACA 600u-6000u-60m-600m-10A ±2.0%
Resistance 600-6K-60K-600K-6M-60MΩ ±1.0%
Capacitance 60n-600n-6u-60u-600u-60mF ±5.0%
Frequency 9.99~9.99MHz ±3.0%
Temperature -20ºC~1000ºC/-4ºF~1832ºF ±2.0%
Duty cycle 0.1%~99.9% ±0.1%
