Transistor hFE Test (connect Adapter )
AC Current
RESISTANCE (Auto Ranging)
Capacitance
Frequency (Auto Ranging)
Baery
Diode and Connuity
1. Overload Protecon: “mA” jack: F0.4A/600V fuse,
“10A” jack: F10A/600V fuse Max.
2. Input Current: “mA” jack: 400mA, “10A” jack: 10A
(For measurements>5A: duraon<10 seconds, interval >15 min.)
3. Voltage Drop:
600µA, 60mA ranges: 60mV
6000µA, 600mA and 10A ranges: 600mV
Frequency Range: 40Hz ~ 400Hz
1. Overload Protecon: F0.4A/600V fuse
2. Open circuit voltage: about 0.5V
1. Overload Protecon 1.5Vand 3V
2. Ranges F0.4A/250V fuse 9V
3. Range 250VDC/AC RMS
4. The approx. voltage of the baery is shown on the LCD
Overload Protecon: 250V DC/AC RMS
1.Open Circuit Voltage: about 0.25V
2. Overload Protecon: 250V DC/AC RMS
1. Overload Protecon: 250V DC/AC rms
2. For connuity test: When the resistance is between 30Ω and 70Ω, the
buzzer may sound or may not sound. When the resistance is more than
70Ω, the buzzer won’t sound
Range hEE Test Current Test Voltage
PNP & NPN 0~1000 Ib≈2µA Vce≈1V
Range Resoluon Accuracy
600µA 0.1µA
±(1.5% of rdg +8dgts)
6000µA 1µA
60mA 10µA
600mA 100µA
10A 100mA ±(2.0% of rdg +10dgts)
Range Resoluon Accuracy
600Ω 0.1Ω
±(1.5% of rdg + 3dgts)
6KΩ 1Ω
60KΩ 10Ω
600KΩ 100Ω
6MΩ 1KΩ
60MΩ 10KΩ ±(1.5% of rdg + 5dgts)
Range Resoluon Accuracy
60nF 10pF
±(8% of rdg + 5dgts)
600nF 100pF
6uF 1nF
60uF 10nF
600uF 100nF
60mF 100uF
Range Accuracy
0~60MHz ±(1.0% + 5)
Range Resoluon Discharge Resistance
1.5V 0.01V 25Ω
3V 0.01V 90Ω
9V 0.01V 220Ω
Range Introducon Remark
The approximate forward
voltage drop will be dis-
played
Open circuit voltage:
about 1.5V
The built-in buzzer will
sound if the resistance is
less than about 30Ω.
Open circuit voltage:
about 0.5V
