UPS user manual
Utilizzo dell’UPS
OMS02083 REV. A 23
5.2 MEASURE DISPLAY
The structure of the MEASURES menu is indicated in the table that follows.
Sub-menu Displayed data Accuracy
INPUT
Rectifier input voltage
(1) (2)
1 V
Rectifier input current
(3)
1 A
Frequency 0.1 Hz
Input power 1 kVA
OUTPUT
Voltage
(1) (2)
1 V
Current
(3)
1 A
Frequency 0.1 Hz
Active power 1 kW
Apparent power 1 kVA
Load percentage 1 %
BYPASS
Voltage
(1) (2)
1 V
Frequency 0.1 Hz
INVERTER
Voltage
(1) (2)
1 V
Frequency 0.1 Hz
AC/DC
Rectifier output voltage 1 V
BATTERY
Voltage and current 1 V / 1 A
Nominal capacity 1 Ah
Residual autonomy 1 min / 1 %
(1)
The voltage measures are always referred to the phase-to-neutral value
(2)
The three voltages are displayed in one screen as “xxx yyy zzz V”
(3)
The three line currents are displayed in one screen as “xxx yyy zzz A”
