Installation and start-up of INGENIO PLUS UPS 30÷40 kVA
Installazione e avviamento INGENIO PLUS UPS 30÷40 kVA
22 OMS02082 REV. D
The UPS must be so installed as to ensure its serviceability and to allow a correct air flow as
much as possible.
With regard to the minimum distances from the walls, for all of the UPS sizes the same
installation conditions apply as indicated in the table below.
UPS POWER
(kVA)
30 40
L - mm 465
P - mm 650
H - mm 1230
X (min.) - mm 100
Y (min.) - mm 500
ADD. CABINET AS553
L1 - mm 503
P1 - mm 647
H1 - mm 1200
The table below shows the air volume required for an optimal ventilation and cooling of the
UPS.
UPS POWER (kVA) 30 40
Air volume (m
3
/h) 450 750
