Installation and start-up of INGENIO PLUS UPS 30÷40 kVA
Installazione e avviamento INGENIO PLUS UPS 30÷40 kVA
OMS02082 REV. D
47
12 START UP FROM
MBCB
MOVE BYP - SWITCH
Move the selector
“NORMAL-BYPASS”
to NORMAL
The load is transferred to the inverter.
Led #5 lit green.
13 START UP END
WAIT PLEASE
The microprocessor checks that all the
output parameters (voltage, current,
frequency) are within the tolerance limits.
14 UPS MODEL
OUTPUT VOLTAGE
