Product Description and
Specifications
Intended Use
The drive unit is intended only for driving your eBike and must
not be used for other purposes.
Product Features (see page 2–3)
The numbering of the components shown refers to the illus-
trations on the graphic pages at the beginning of the manual.
All illustrations of bike parts except for the drive unit, on-
board computer including operating unit, speed sensor and
the corresponding holders are schematic and may differ on
your eBike.
1 Display-function button “i”
2 Bike lights button
3 On-board computer
4 Holder for on-board computer
5 On/Off button for on-board computer
6“RESET” button
7 USB port
8 Protective cap of USB port
9 Drive unit
10 Operating unit
11 Display-function button “i” on the operating unit
12 Decrease assistance level/scroll down button “–”
13 Increase assistance level/scroll up button “+”
14 Push-assistance/start-assistance button “WALK”
15 Lock latch for on-board computer
16 Locking screw for on-board computer
17 Speed sensor
18 Spoke magnet of the speed sensor
USB charging cable (Micro A – Micro B)
Display elements of on-board computer
a Drive unit assistance indicator
b Assistance-level indicator
c Light indicator
d Text indication
e Value indication
f Speed indication
g Shift recommendation: higher gear
h Shift recommendation: lower gear
i Battery charge-control indicator
Technical Data
Drive Unit Drive Unit Cruise
Article number
0 275 007 033
Rated continuous output
W250
Torque at drive, max.
Nm 60
Rated voltage
V36
Operating temperature
°C –5...+40
Storage temperature
°C –10...+50
Degree of protection
IP 54 (dust and splash
water protected)
Weight, approx.
kg 4
Drive Unit Drive Unit Speed
Article number
0 275 007 031
Rated continuous output
W250
Torque at drive, max.
Nm 60
Rated voltage
V36
Operating temperature
°C –5...+40
Storage temperature
°C –10...+50
Degree of protection
IP 54 (dust and splash
water protected)
Weight, approx.
kg 4
Drive Unit Drive Unit CX
Article number
0 275 007 027
Rated continuous output
W250
Torque at drive, max.
Nm 75
Rated voltage
V36
Operating temperature
°C –5...+40
Storage temperature
°C –10...+50
Degree of protection
IP 54 (dust and splash
water protected)
Weight, approx.
kg 4

Bosch Active Line Specifications

General

Rated Power	250 W
Max Torque	40 Nm
Weight	3.2 kg
Maximum Assistance Speed	25 km/h
Operating Voltage	36 V
Walk Assistance	Yes
Battery Compatibility	Bosch PowerPack
Display Compatibility	Bosch Purion, Intuvia
