Control Panels System wiring diagrams | en 105
Bosch Security Systems, Inc. Installation Manual 2018.07 | 10 | F.01U.303.996
Callout ᅳ Description Callout ᅳ Description
3 ᅳ Supervised connection to Zone A power from an on-
board point of the panel
8 ᅳ Supervised smoke detector to B LOOP positive
4/5 ᅳ Connection to common the control panel (one
connection only)
9 ᅳ Supervised smoke detector to A LOOP positive
