16 en | System overview Control Panels
2018.07 | 10 | F.01U.303.996 Installation Manual Bosch Security Systems, Inc.
3 System overview
This section has the following information:
– Parts list, page 16
– Control panel capacities, page 16
– Accessories, page 20
– Features, page 17
3.1 Parts list
Control panels ship assembled from the factory with the following parts:
Literature
– Control Panels (B9512G/B8512G) UL Installation Manual
– Control Panels (B9512G/B8512G/B5512/B4512/B3512) Operation Manual
– Control Panels (B9512G/B8512G) SIA Quick Reference Guide
– Control Panels (B9512G/B8512G) Documentation CD
– Product Label in French
– 7000/9000 Series Point Chart Label
HW pack
– 1 kΩ EOL resistors
– Battery wires
Assembly
– PC board with protective cover
– Mounting skirt
– One #6 x 3/4-inch screw
3.2 Control panel capacities
Features B9512G/
B9512G-E
B8512G/
B8512G-E
Number of users 2000 500
Total number of doors 32
1
8
1
Number of cards/tokens 2000 500
Number of custom functions 32 8
Number of areas 32 8
Number of points 599 99
Number of outputs 599 99
Total number of keypads 32
2
16
2
Number of octo-intput modules (B208) 59 9
Number of POPEX modules (B299) 6 1
Number of octo-output modules (B308) 59 9
Number of on-board Ethernet ports (“E” control panel variants do not include an
Ethernet port)
1 1
Number of B426 or B450 modules 2 2
Number of plug-in telephone communication modules (B430) 2 2
