Control Panels System wiring diagrams | en 97
Bosch Security Systems, Inc. Installation Manual 2018.07 | 10 | F.01U.303.996
18 System wiring diagrams
Notice!
UL notifications
Add additional power using only a UL Listed 12.0 VDC regulated, power-limited power supply
such as the B520.
All terminals except Outputs A (1), B (2), and C (3) (Terminals 6, 7, and 8) are supervised.
For proper supervision, do not loop wire under terminals. Break the wire run to provide
supervision of connections.
