96 en | Control panel board overview Control Panels
2018.07 | 10 | F.01U.303.996 Installation Manual Bosch Security Systems, Inc.
Callout ᅳ Description For more information, refer to:
12 ᅳ BASE-T LED (green) On-board Ethernet connection, page 48
13 ᅳ On-board Ethernet connector
14 ᅳ LINK LED (yellow)
15 ᅳ USB connector USB power, page 67
16 ᅳ USB POWER STATUS LED
