116 en | Approved applications Control Panels
2018.07 | 10 | F.01U.303.996 Installation Manual Bosch Security Systems, Inc.
D1257RB/
D1257
______ 104 xQty =______ 10+ xQty =______ 225 xQty =______
D1260/D1260B ______ 140 xQty =______ 140 xQty =______ 250 xQty =______
D8125 ______ 60 xQty =______ 60 xQty =______ 60 xQty =______
D8125MUX ______ 140 xQty =______ 140 xQty =______ 140 xQty =______
D8128D ______ 25 xQty =______ 25 xQty =______ 50 xQty =______
D8129 ______ 20 xQty =______ 20 xQty =______ Refer to
footnote
1
=______
D9127T/U ______ 0.8 xQty =______ 0.8 xQty =______ 0.8 xQty =______
D9210C ______ 110 xQty =______ 100 xQty =______ 110
6
xQty =______
Ratings of other devices in the system that are not shown above:
____ ______ _____ xQty =______ ______ xQty =______ ____ xQty =______
____ ______ _____ xQty =______ ______ xQty =______ ____ xQty =______
____ ______ _____ xQty =______ ______ xQty =______ ____ xQty =______
____ ______ _____ xQty =______ ______ xQty =______ ____ xQty =______
Total A=______ Total B=______ Total C=______
1
The In Alarm calculation for the module is: 20 xQty + (16.25 x number of relays).
2
Currents listed are for the B450 only. Include plug-in device currents in calculations.
3
If using the proximity reader, add 100 mA to columns A, B, and C before calculating.
4
38 mA for each active relay.
5
Value=Minutes of alarm operation/60
6
Use 110 mA + reader. Do not exceed 260 mA.
Table19.10: Current rating chart for standby battery calculations
General ampere-hour (Ah) calculation
In this calculation, use Total B and Total C from the above table, and standby time (in hours)
and alarm time (in minutes) from the table below.
(Total B x standby time (in hours)) + (Total C x (alarm time (in minutes) / 60)) x1.15 =Total Ah
of battery
Total Ah requirements must not exceed the Ah capacity of batteries:
– One D126 Battery=7 Ah
– Two D126 Batteries=14 Ah
– One D1218 Battery=17.2 or 18 Ah
– Two D1218 Batteries=34.4 or 36 Ah
Application Standby time (in hours)
minimum
Alarm time (in minutes)
minimum
Residential Burglary 4 4
Proprietary Burglary 4 N/A
Central Station (Bank) 72 N/A
Central Station (Mercantile) 4 N/A
