Bosch C7 User Manual

1 | english
09.2014 | C7 | Battery charger Automotive Aftermarket
2 Introduction
2 Scope of delivery
3 List of parts
3 Technical data
4 Safety
4 Notes on safety
6 Product description
7 Operation
7 Prior to start-up
7 Connection
7 Disconnection
7 Memory function
8 Mode selection
8 Back-up mode/Power supply unit
9 Regeneration mode
10 Charge status
10 Pulse charging
10 Appliance protection function
10 Overheating protection
11 Maintenance and upkeep
11 Disposal
11 Information
11 Service
11 Important note: Consumer protections
12 Warranty
Contents
5
13 + 17
12
16
1
3
4
15
14
9
6
8
7
11
10
4 a
4 b
2

Bosch C7 Specifications

General

Power plug	Type C (Europlug)
LED indicators	Charging, Stand-by
Output current	3.5 A
Built-in display	No
Charging current	1.5/3.5/5/7 A
Charging voltage	12/24 V
Battery capacity (max)	230 Ah
Battery capacity (min)	14 Ah
Power protection features	Overcharge, Overheating, Reverse polarity, Short circuit
International Protection (IP) code	IP65

Weight and Dimensions

Depth	65 mm
Width	197 mm
Height	108 mm
