Bosch C7 User Manual

english | 2 3 | english
09.2014 | C7 | Battery charger Automotive AftermarketAutomotive Aftermarket Battery charger | C7 | 09.2014
Introduction
List of parts
1 Charger
2 Mounting braket
3 Power cord with mains connector
4 Charging cable with cable lug
(red and black)
4a Fuse
4b Plug
5 (+) Terminal (red)
6 (–) Terminal (black)
7 Standby / power indicator
8 Mode selection button
9 Reverse polarity protection
10 Charge status
11 Charge status “ok” (lit)
Charge maintenance (flashing)
12 Mode 1 | 12 V (motorcycle / car charging)
13 Mode 2 | 12 V (winter charging, AGM)
14 Mode 3 | 12 V (power back-up)
15 Mode 4 | 12 V (regeneration)
16 Mode 5 | 24 V (truck charging)
17 Mode 6 | 24 V (winter charging, AGM)
Technical data
Primary
Rated
input voltage: 230 V ~ 240V / 50 Hz
Starting current: < 50 A
Rated input current: max. 1.2 A (rms value)
Power input: 135 W
Carefully study the operating instructions with
the illustrations page folded out. The operating
instructions should be kept in a safe place and
submitted together with the device in the event
of this changing hands.
The Bosch C7 is suitable for the charging and
trickle charging of 12 V and 24 V lead batteries
with liquid electrolyte, AGM or gel. Only operate the
charger in a well ventilated area.
Secondary
Rated output voltage: 12 V
24 V
Charging voltage: 28.8 V / 29.4 V (± 0.6 V),
14.4 V /14.7 V (± 0.25 V),
13.6 V / 16.5 V (± 0.25 V)
Charging current: 7 A (± 0.7 A),
5 A (± 0.5 A),
3,5 A (± 0.35 A),
1,5 A (± 0.3 A)
Rated output current: 3.5 A / 7 A
Ripple
1
: max. 150 mV
Backflow current
2
: < 5 mA (no AC input)
Degree of protection: IP 65 (dustproof, water-
tight)
Battery type: 12 V + 24 V lead acid
battery (AGM, GEL, open
and VRLA)
Battery capacity: 12 V:14 Ah–230 Ah /
24 V:14 Ah–120 Ah
Fuse (internal): 10 A
Noise level: < 50 dBA
Ambient
temperature: 0 to + 40 °C
Dimensions: 197 x 108 x 65 mm
(L x W x H)
The following pictograms/symbols are used in these operating instructions/and product:
The manufacturer cannot accept any liability for
damage arising from improper use. The device is
not intended for commercial applications.
Scope of delivery:
1 Charger
1 Power cord with mains connector
2 Terminals (1 red, 1 black)
1 Charging cable with 2 cable lugs
1 Set of operating instructions
1 Wall mount
Consult the operating instructions
Heed the warnings and
safety instructions
Caution: Risk of electric shock
Hazardous voltage – Risk of fatal injury
Danger of explosion!
Fire hazard!
Keep children and others away from the
battery charger when in operation.
Never dispose of electrical equipment
together with household refuse.
For indoor use only.
Dustproof, watertight
Danger of acid burns!
IP65

Bosch C7 Specifications

General

Power plug	Type C (Europlug)
LED indicators	Charging, Stand-by
Output current	3.5 A
Built-in display	No
Charging current	1.5/3.5/5/7 A
Charging voltage	12/24 V
Battery capacity (max)	230 Ah
Battery capacity (min)	14 Ah
Power protection features	Overcharge, Overheating, Reverse polarity, Short circuit
International Protection (IP) code	IP65

Weight and Dimensions

Depth	65 mm
Width	197 mm
Height	108 mm
