Bosch C80-Li - Device description

ENCharger Bosch C80-Li I Operating instructions
13
Device description
1 Charger
2 Mounting hook
3 Mains cable with mains connection
4 Charging cable with cable plug (red
and black)
a Plug
5 Charging cables with ring eyelets
(red and black)
a Plug
b Fuse
6 Charging cable with terminal clamps
(red and black)
a Plug
7 (+) Terminal clamp (red)
8 (–) Terminal clamp (black)
9 Standby
10 Mode selection button
11 Reverse polarity protection + -
12 Battery capacity indication
Battery capacity: Lo %
Battery capacity: 25 %
Battery capacity: 50 %
Battery capacity: 75 %
Battery capacity: 100 %
13 Mode 1 | 12 V
(Car Charging)
14 Mode 2 | 12 V (Charging at
0-4 °C in winter, or AGM)
15 Mode 3 | 12 V (LiFePO)
16 Mode 4 | 12 V (Quick)
17 Mode 5 | 12 V
(Regeneration)
18 Mode 6 | 6 V (Normal)
19 Modus 7 | 12V (Power supply)
20 Mode 8 | 6 V
Push charging
21 Mode 9 | 12 V
Push charging
(1)
(9)
(10)
(4a)
(5)
(5a)
(5b)
(3)
(2)
(5a)
(12)
(11)
(18)
(15)
(20)
(14)
(16)
(21)
(17)
(19)
(13)
(12)
(12)
(4)(4)
(6a)(6a)
(6)
(8)
(7)
