Charger Bosch C80-Li I Operating instructions EN
14
1 Technical data
Technial Data
Input voltage 230 VAC / 50 Hz
Starting current < 50 A
Rated input current Max. 3 A (rms value)
Power input 380 watts
Nominal output voltage DC 6 V / 12 V
Charging voltage 7.2 V / 14.4 V (± 0.25 V),
14.2 V / 14.7 V (± 0.25 V),
16.5 V (± 0.5 V),
13.6 V (± 0.5 V)
Charging current 15 A (± 10 %),
5 A (± 10 %),
20 A (± 10 %),
1.5 A (± 0.3 A),
1.5 A (± 0.5 A)
Rated output current 5 A & 15 A
< 5 mA (no AC input)
Degree of protection IP65 (dustproof, watertight)
Battery type 12 V LiFePO and 6 V & 12 V Lead-Acid type (WET,
EFB, GEL, AGM, open and VRLA)
Battery capacity 6 V: 14 Ah – 120 Ah, 12 V: 30 Ah – 400 Ah
Fuse (internal) 5 A
Fuse (fuse holder) 40 A
Noise level < 50 dB(A)
Temperature 0 °C to + 40 °C
Dimensions 215 x 112 x 65.4 mm (L x W x H)
1)
power is connected.
