Charger Bosch C80-Li I Operating instructions EN
18
Mode Output Indication Operating Instructions
Supporting Battery
Types
Mode 5
Regeneration
16.5 V
1.5 A
Press the button 5 times to
select Mode 5
12 V & R icon lights up
Suitable for the
regeneration of 12 V
batteries after short-
term extreme discharge.
Capacity of > 30 Ah in
normal state
Mode 6
6 V Mode
7.2 V
5 A
Press the button once to
select Mode 6
6 V icon lights up
6 V WET, EFB and the
majority of GEL
batteries. Capacity of >
14 Ah in normal state
Mode 7
Power Supply
13.6 V
5 A
Not connect any battery.
Press and holding mode
button for 5s to enter mode
7
12 V & power supply icon
lights up
Suitable for providing
back-up. Can be used to
power the vehicle
electronics whilst
changing the 12 V
battery
Mode 8
6 V Push Mode
1.5 A
Press and hold mode button
for 5 seconds, Push icon on
alternatively
MODE button once more to
select 6 V push mode
6 V batteries. Battery
battery voltage is
between 0.5 V to 3.75 V
Mode 9
12 V Push-Mode
1.5 A
Press and hold mode button
for 5 seconds, Push icon on
alternatively
press MODE button once
more to select 12 V push
mode
12 V batteries. Battery
battery voltage is
between 0.5 V to 3.75 V
Note:
1) Quick mode only allow user operate about 5 minutes Max., and user need wait 30
minutes between 2 quick mode operation.
2) For regeneration mode, make sure to disconnect all connections between the battery
and the vehicle electrical system.
3) On certain vehicles it is essential not to disconnect the vehicle electronics from the
power supply on battery replacement. In such cases, the power supply mode can be
used to power the vehicle electronics whilst changing the battery. If load voltage is
below 7.5 V, the charger will change to standby mode. There is no reverse polarity
protection in this mode.
