Operation
Initial Operation
Switching On (see figures A1 –A2)
n Dis-engage the safety lock 7 by moving the button as
shown.
o Fully insert finger and pull the
On/Off switch 9 back from pos-
tion „1.“ to postion „2.“ (work-
ing position) and hold.
p To close the blade 2 pull the
On/Off switch 9 back to postion
“3.”. To open the blade 2 return
On/Off switch 9 to position “2.”.
Switching Off (see figure A3)
q Release the On/Off switch 9 and allow it to return to
position “1.”. The blade 2 will then return to the fully
open position.
r Engage the safety lock 7 by moving the button as
shown.
Note: If the On/Off switch 9 is released quickly then the
blade 2 will not return to the fully open position, but will
stay in its current position. Pulling the On/Off switch 9 to
position “2.” will return the blade 2 to the fully open po-
sition.
2.
1.
3.
Working Advice
Pruning Tips (see figures B1 – B10)
f Never operate the machine in an awkward posture.
This may cause serious injury.
f Keep your free hand away from the cutting area. Nev-
er touch the blades. They are very sharp and you may
cut yourself.
B1 Always wear protective gloves while pruning.
B2 Never cut too close to the stem so the wound can
heal properly.
B3 Always make the cut about 8 mm from the bud.
B4 The cut should slope away from the bud so the rain
can run off.
B5 If you remove an entire stem, cut back to the point
where it branched.
B6 Never push the blade of the pruner into the ground
to cut suckers.
B7 Cut branches one by one as shown.
B8 Remove overcrowds or crossing stems.
B9 Remove thin or weak growth.
B10 Always remove dead, damaged and diseased
branches.
24 | Deutsch 2 |
24
English
F 016 L70 560 | (25.11.08) Bosch Power Tools
