n Engage the safety lock 7 by moving the button as
shown.
o Using a 5 mm hex wrench socket key (not provided) to
remove the blade screw 10 which secures the blade.
Remove spacer 11.
pqRemove the blade 2 as shown. Be careful not to al-
low any foreign matter to become attached to the blade
gear and do not damage it.
rsInsert blade 2 as shown. Ensure that the blade 2 has
located in the transmission link 12.
t Rotate the blade 2 to the fully open postion. Check the
blade 2 location by gently pulling. If the blade 2 is correct-
ly located then blade cannot be removed.
Incorrect location of the blade will damage the ma-
chine.
u Refit spacer 11. Ensure spacer 11 is located through
fixed blade and moving blade.
Refit the blade screw 10 and tighten it by using a 5 mm
hex wrench socket key (not provided). Do not overtight-
en.
f Ensure replacement parts fitted are Bosch approved.
After Pruning/Storage
Always wear protective gloves when using, adjusting
or cleaning the machine.
Clean the exterior of the machine thoroughly using a soft
brush and cloth. Do not use water, solvents or polishes.
Remove all debris.
Always lubricate the cutting blade with protective spray
before storage.
Store the machine in a secure, dry place out of the reach
of children with the safety lock 7 engaged. Do not place
other objects on top of the machine.
After-sales Service and Customer Assistance
Our after-sales service responds to your questions con-
cerning maintenance and repair of your product as well as
spare parts. Exploded views and information on spare
parts can also be found under:
www.bosch-pt.com
Our customer consultants answer your questions con-
cerning best buy, application and adjustment of products
and accessories.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: +44 (0844) 736 0109
Fax: +44 (0844) 736 0146
E-Mail: SPT-Technical.de@de.bosch.com
