1.2 General safety instructions
HNotices for the target group
These installation instructions are intended for qualified persons who
are skilled in dealing with refrigeration engineering and HVAC technology
and also electrical systems. All system-relevant instructions must be
observed. Failure to comply with instructions may result in material
damage and personal injury, including danger to life.
▶ Before carrying out the installation, read the installation instructions
of all system components.
▶ Observe the safety instructions and warnings.
▶ Follow national and regional regulations, technical regulations and
guidelines.
▶ Record all work carried out.
HGeneral dangers posed by the refrigerant
▶ This appliance is filled with refrigerant R32. If the refrigerant gas gets
into contact with fire, it may generate toxic gas.
▶ Thoroughly ventilate the room if refrigerant leaks during the
installation.
▶ Check the tightness of the system following the installation.
▶ Do not to let any other substance than the specified refrigerant (R32)
into the refrigerant cycle.
HSafety of electrical devices for domestic use and similar
purposes
The following requirements apply in accordance with EN 60335-1 in
order to prevent hazards from occurring when using electrical
appliances:
“This appliance can be used by children of 8 years and older, as well as
by people with reduced physical, sensory or mental capabilities or
lacking in experience and knowledge, if they are supervised and have
been given instruction in the safe use of the appliance and understand
the resulting dangers. Children shall not play with the appliance.
Cleaning and user maintenance must not be performed by children
without supervision.”
“If the power cable is damaged, it must be replaced by the manufacturer,
its customer service department or a similarly qualified person, so that
risks are avoided.”
HHandover to the user
When handing over the air conditioning system, explain the operation
and operating conditions to the user.
▶ Explain operation – with particular emphasis on all safety-related
actions.
▶ Highlight the following points in particular:
– Point out that modifications or repairs may be carried out only by
an approved contractor.
– To ensure safe and environmentally compatible operation, an
annual inspection, and also cleaning and maintenance if required,
must be carried out.
▶ Point out the possible consequences (personal injury and possible
danger to life or material damage) of not carrying out inspection,
cleaning and maintenance correctly, or omitting it altogether.
▶ Hand over the installation and operating instructions to the user for
safekeeping.
1.3 Notices regarding these instructions
The figures are shown together at the end of these instructions. The text
contains references to the figures.
Depending on the model, the products may be different to those shown
in these instructions.
2Product Information
2.1 Declaration of conformity
The design and operating characteristics of this product comply with the
European and national requirements.
The CE marking declares that the product complies with all the
applicable EU legislation, which is stipulated by attaching this
marking.
The complete text of the Declaration of Conformity is available on the
Internet: worcester-bosch.co.uk.
2.2 Scope of delivery
The scope of delivery of the possible appliances is shown in Fig. 8 and 9.
The appliances are shown as an example and deviations are possible.
[1] Outdoor unit (filled with refrigerant)
[2] Indoor unit (filled with nitrogen)
[3] Bio filter
[4] Copper nut (2x)
[5] Drainage elbow with gasket
[6] Remote controller
[7] Remote control Holder with fixing screw
[8] Magnet ring
[9] Set of printed documents for product documentation
[10] 4 anti-vibration couplings for the outdoor unit
2.3 Twin combination
The appliances can be installed as so-called twin combination. In doing
so, an outdoor unit is combined with two indoor units of the same type.
The indoor units must be installed at the same height.
▶ Observe the possible combinations in table 2.
▶ Observe the dimensions in Fig. 32.
▶ Arrange the branch joints horizontally.
Table 2 Possible twin combinations
2.4 Product dimensions and minimum clearances
2.4.1 Indoor unit and outdoor unit
Outdoor Unit
Figs. 12 to 13.
Indoor Unit
Figs. 10 to 11.
[1] Pipe connection (gas)
[2] Condensate pipe
[3] Pipe connection (liquid)
[4] Checkmark
2.4.2 Refrigerant lines
Key to figure 14:
[1] Pipe on gas side
[2] Pipe on liquid side
[3] Siphon-shaped elbow as oil separator
If the indoor units are positioned lower than the outdoor unit, install a
siphon-shaped elbow on the gas side after no more than 6 m and every
6 m thereafter ( figure 14, [1]).
Outdoor unit Indoor Unit
CL5000L 105 E/
CL5000L 105 E-3
2 × CL5000iL CF 53 E
CL5000L 140 E-3 2 × CL5000iL CF 70 E
