Installation en
15
Body wall thickness: 16 mm
1. Screw the mounting pieces to the body on the left
and right. ¨
2. Remove the tabs from the bottom of the mounting
pieces. ©
Body wall thickness: 19 mm
1. Fold out the tabs on both of the mounting pieces. ¨
2. Screw the mounting pieces to the body on the left
and right. ©
3. Remove the tabs from the bottom of the mounting
pieces. ª
Preparing the appliance
Connect the power cord provided to the appliance.
5Installation
Installation
Sliding the appliance up into place
1. Slide the appliance up into place and make sure it is
positioned correctly. ¨
2. Measure the distance between the appliance and
the wall, and mark this on the filler strip.
3. If required, shorten the filler strip to the required
dimension. ©
$
%
[
PP
%
&
PP
[
PP
$
