7
¡ Do not connect the appliance to an exhaust gas
system for combustion products.
¡ Never install the appliance in boats or in vehicles.
¡ The warranty applies only when using the appli-
ance as intended.
¡ Before installing the appliance, check that the
local conditions of the supplier are compatible
with the appliance settings specified on the rating
plate (type of gas and pressure, power, voltage).
¡ Secure the power cord to the cabinet to prevent it
from touching hot parts of the oven or hob.
¡ Before any work is carried out on the appliance,
switch off the power supply and the gas supply.
¡ Connect the appliance to the power supply using
the earth.
¡ Do not make any changes to the inside of the ap-
pliance. If required, contact our technical cus-
tomer service.
Before installing
¡ This appliance is a class 3 appliance in accord-
ance with the EN 30-1-1 standard for gas appli-
ances: Built-in appliance.
¡ The unit in which the appliance is installed must
be stable and secured appropriately.
¡ The units in the vicinity of the appliance, the lamin-
ated panels and the adhesive with which they are
secured must be made of non-flammable, heat-
resistant materials.
¡ Do not install this appliance above refrigerators,
washing machines, dishwashers or similar.
¡ The appliance must only be installed on an oven
with forced ventilation. Check the dimensions of
the oven in the installation instructions for the
oven.
¡ If you install an oven underneath the hob, the work
surface thickness may differ from the dimensions
given in these instructions. Take note of the in-
formation in the oven installation instructions.
¡ If you install an exhaust air fan or an extractor
hood, refer to the installation instructions for these.
Always observe the minimum vertical distance to
the hob.
→Fig.
1
Preparing the units
¡ Make a cut-out in the worktop with the required di-
mensions.
→Fig.
2
, →Fig.
3
¡ Seal the cut surfaces of wooden work surfaces
with a special glue seal to protect them from mois-
ture.
¡ If there is no built-in oven underneath the hob, in-
sert a non-flammable separator (e.g. metal or ply-
wood) at a distance of 10 mm from the hob. This
prevents access to the underside of the hob. The
distance from the intermediate floor to the mains
connection for the appliance must be at least 10
mm.
→Fig.
4
, →Fig.
5
Positioning the appliance
Note:Do not remove the adhesive seal fitted on the
lower edge of the hob. The adhesive seal prevents
the penetration of liquids.
Do not use silicone to bond the appliance to the
worktop.
1. Position the hob with the upper side facing down
on a flat, stable surface.
2. Loosen the screws on the brackets so they can
turn freely. You do not need to fully undo the
screws on the brackets.
→Fig.
6
3. Turn the hob around and insert it into the recess.
Insert the hob in the front of the recess.
→Fig.
7
4. Turn the brackets and tighten them fully.
→Fig.
8
The position of the brackets depends on the work-
top thickness.
Removing the appliance
1. Disconnect the appliance from the electricity and
gas connections.
2. Unscrew the brackets and proceed in reverse or-
der.
Connecting the gas
Observe the country-specific guidelines.
CAUTION‒Risk of explosion!
A gas leakage may cause an explosion.
▶ If any connection is handled, check the seal.
¡ Arrange the gas connection so that the shut-off
valve is accessible.
¡ Ensure that the information on the rating plate re-
garding the gas type and gas pressure complies
with the local connection conditions.
¡ Connect the appliance to a fixed gas pipe or a
flexible metal pipe.
¡ The flexible metal pipe must not come into contact
with the moving parts of the unit in which the ap-
pliance is installed (e.g. a drawer) and must not
be routed through any spaces which might be-
come obstructed.
¡ Gas connection elbow on the appliance: G 1/2.
¡ Do not move or twist the gas connection elbow.
Spare parts for gas connection
You can obtain the gas connection parts from the
technical customer service.
Gas connection G 1/2
▶ Insert the seal between the gas connection of the
appliance and the gas supply.
→Fig.
9
Electrical connection
¡ This appliance is type Y: The connection cable
must only be replaced by technical customer ser-
vice and not by the user. The cable type and the
minimum cross section must be respected.
¡ The hobs are supplied with a power cord with or
without a plug.
¡ Only connect appliances that are fitted with a plug
to a correctly installed socket with protective earth
conductor.
¡ If the plug is not accessible to the user, an all-pole
isolating safety switch with a minimum contact
opening of 3 mm must be provided.
→Fig.
10
Converting the gas type
If the country's regulations allow, this appliance can
be adapted to other types of gas, if these are listed
on the rating plate.
You can find the right parts in the bag that is sup-
plied with the appliance or you can obtain them from
customer service. The table →Fig.
27
shows the
right combination for the relevant burner and gas
type.
Economy burner
Standard-output burner
High-output burner
