Bosch CSG656B 2B Series Installation Instructions

8
Dual-wok multi-crown burner
¡ 1-Outer flame
¡ 2-Inner flame
Tools
Contact technical customer service to purchase the
relevant tools.
Removal lever 483196
Removing the upper part of the appliance (glass
plate with cut-out profiles)
1. Remove the pan supports, burner caps, distribut-
ors and rotary knobs.
2. Undo the screws on the burners.
→Fig.
11
3. Move the removal lever under the metal cut-out
profile into the area marked for the hob model
and loosen the front clip fastener.
→Fig.
12
Only use the lever under the cut-out profiles or the
metal frame of the hob.
4. Carefully lift the glass plate with the cut-out pro-
files to release the rear clip fastener.
Removing the circuit board
Tip:The circuit board is secured to the holder by
fastening pins at the sides and in the middle. Push
the fastening pins carefully without damaging them.
If one of the pins breaks, the entire holder must be
replaced.
ATTENTION!
The circuit board can be damaged by improper
handling.
▶ Handle the circuit board carefully.
▶ Use anti-static shields or hold the circuit board at
the edges.
▶ Never touch the surfaces of the circuit board on
which there are components or conducting tracks.
1. Undo the fastening pins on one side.
2. Release the fastening pins in the middle by press-
ing on them from both sides with your fingers.
3. Undo the fastening pins on the other side and re-
move the circuit board.
→Fig.
13
Adjusting the taps
Requirement:The upper part of the appliance and
the circuit board are removed. →"Removing the up-
per part of the appliance (glass plate with cut-out
profiles)", Page8 →"Removing the circuit board",
Page8
1. Remove the cylindrical parts and springs from the
fittings spindle.
2. When adjusting the bypass screws (M), refer to
the table →Fig.
27
.
‒ A: Firmly tighten the bypass screws.
‒ B: The bypass screws must be flush with the fit-
ting.
→Fig.
14
Replacing the nozzles
▶ Replace the nozzles using the appropriate wrench
and tighten them carefully to guarantee the seal.
→Fig.
15
Ensure that the nozzle does not become detached
during removal or fastening.
Replacing the outer flame nozzle on the multi-crown
burner
Requirement:The upper part of the appliance has
been removed. →"Removing the upper part of the
appliance (glass plate with cut-out profiles)",
Page8
1. To gain access to the main nozzle, loosen the
fastening screw and pull the sleeve back.
→Fig.
16
2. Remove the nozzle by turning it anti-clockwise ⁠
and screw in the new outer flame nozzle ⁠.
→Fig.
17
3. Set the spacing of the adjustment sleeve for the
air supply to dimension Z, as shown in the table
→Fig.
27
.
→Fig.
18
4. Tighten the fastening screw.
→Fig.
19
Replacing the inner flame nozzle on the multi-crown
burner
Requirement:The upper part of the appliance has
been removed. →"Removing the upper part of the
appliance (glass plate with cut-out profiles)",
Page8
1. Unscrew the tube by applying pressure to the
sleeve in the opposite direction to hold it in place
and pulling the tube out of the sleeve ⁠.
→Fig.
20
2. Remove the sleeve.
→Fig.
21
3. Remove the inner flame nozzle from the sleeve
and screw in the new nozzle.
→Fig.
22
4. Screw the sleeve and the tube back into their ori-
ginal position.
5. Depending on the type of gas, it may be neces-
sary to set the spacing to that specified in the
table →Fig.
27
for the value Y using the clip for
adjusting the air supply.
→Fig.
23
Reinstalling the appliance
▶ Install the appliance components in reverse order.
Checking if equipment is working
1. Check that turning the rotary knob between the
position for maximum power and the position for
minimum power does not cause the burner to go
out or result in backfire.
2. If the gas flow from the burner is not correct, in
the table →Fig.
27
, check whether the nozzle and
the position of the bypass screw are correct.
Documenting the gas type conversion
▶ Attach the sticker showing the new gas type near
to the rating plate.
Calibrating the electronics
▶
→Fig.
24
, →Fig.
25
, →Fig.
26
Always recalibrate the electronics after reas-
sembling.
ru
Безопасность при монтаже
При установке прибора соблюдайте данные указания по
технике безопасности.
¡ Внимательно прочитайте данное руководство.
¡ Приведенные в данном руководстве рисунки являют-
ся ориентировочными.
