Bosch CSG656BS7B User Manual

en Installation instructions
44
29.2 Appliance dimensions
You will find the dimensions of the appliance here
29.3 Installation below a worktop
Observe the installation dimensions and the installation
instructions when installing below a worktop.
¡ To ventilate the appliance, the intermediate floor
must have a ventilation cut-out.
¡ The worktop must be secured to the fitted unit.
¡ Observe any available installation instructions for the
hob.
¡ Observe different national installation instructions for
the hob.
29.4 Installation underneath a hob
If the appliance is installed under a hob, the following
minimum dimensions must be adhered to (including
substructure, if applicable).
The minimum worktop thickness ⁠ a is based on the
required minimum clearance ⁠.
Hob type a raised in mm a flush in mm b in mm
Induction hob 42 43 5
Full-surface induction hob 52 53 5
Gas hob 32 43 5
1
Electric hob 32 35 2
1
Observe different national installation instructions for the hob.

Bosch CSG656BS7B Specifications

General

Oven size	Medium
Rotisserie	No
Top heating	-
Number of ovens	1
Hot air grilling	Yes
Total oven power	- W
Oven thermostat range	30 - 250 °C
Total oven(s) interior capacity	47 L
Door hinge	down
Cord length	1.5 m
Display type	TFT
Certification	CE, VDE
Door material	Glass
Display diagonal	2.5 \
Housing material	Glass, Stainless steel
Appliance placement	Built-in
Water tank capacity	1 L
Current	16 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency index (EEI)	81.3
Energy consumption (conventional)	0.73 kWh
Energy consumption (forced convection)	0.61 kWh
Package depth	690 mm
Package width	660 mm
Package height	530 mm
Lamp type	LED

Weight and Dimensions

Depth	548 mm
Width	594 mm
Weight	33834 g
Installation compartment depth	550 mm
Installation compartment width	568 mm
Installation compartment height	455 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	450 mm
