Bosch CTL836E 6 Series User Manual

41
en
Overview
Overview
1 Appliance door
a Recessed grip (for opening the door)
b Drip plate
2 Control panel (see next page)
a Control ring
b Information display
c Touch display (left and right)
3 Outlet system (co󰀨ee, milk, hot
water), height-adjustable
a Cover
4 Milk system
a Snap lever
b Beverage outlet (upper part,
lower part)
c Milk tube (2 pieces)
d Connecting element, metal (for
magnet holder)
5 Mains switch J (power supply)
6 Accessory drawer
(for quick reference guide and
accessories)
a Quick reference guide
b Measuring spoon
c Water hardness strip
d Milk tube (set)
7 Removable water tank
a Lid for water tank
8 Removable bean container
a Lid for bean container
9 Slide regulator for grinding degree
setting
10 Magnet holder (for connecting
element)
11 Removable drawer
(for ground co󰀨ee/cleaning tablet)
12 Holder (for milk tube)
13 Protective cover (for brewing unit)
14 Brewing unit
a Locking mechanism
b Cover
15 Eject lever
16 Removable Drip tray
a Drip tray cover
b Co󰀨ee grounds container
17 Collecting tray
18 Holder
a Suction pipe
19 Rating plate (E number, FD)
20 Shelf with sensor (for milk container)
21 Milk container
a Stainless steel container
b Lower part of the lid
c Upper part of the lid
F
Further information about the appli-
ance, such as how to change the
opening angle of the door, can be
found in the assembly instructions.
Controls
The appliance features userfriendly menu
navigation to ensure that operation is as
easy as possible while at the same time
o󰀨ering a wide range of functions. That
means a range of options can be selected
with just a few operating steps.
Mains switch J
The power switch J (with the door
open) is used to switch the appliance on, or
to switch it o󰀨 fully (power supply o󰀨).
F
Important: Do not press the mains
switch while the appliance is in use.
Switch off the appliance only when
it is in energy saving mode, so that it
can rinse automatically.
Control panel (touch eld)
F
Important: These operating
instructions refer to several models.
In some models I and C are
touchscreen elements.
I on/o󰀨
Press I to switch on the appliance or
put it into energy saving mode. The appli-
ance is rinsed automatically.
The appliance does not rinse if:
■ if it is still warm when switched on, or
■ if no co󰀨ee was dispensed before it was
switched o󰀨.
The appliance is ready for use as soon as
the symbols for the drinks selection appear
on the display.
