Graphic-based manual
DB-CO | D-SetCO – 6721848552 (2022/02)
WARNING
Risk to life!
Do not try to repair the device. It has the risk of electrical shock or malfunction if the
device is tampered with.
5 Graphic-based manual
When reading the graphic-based manual, please consider the following:
Graphic number and relevant title
Each graphic has a number associated that can be found at the bottom of the frame.
Some graphics have a relevant correspondent legend, such as:
• Graphic 11 – warm up
• Graphic 13 – normal operation
• Graphic 14 – warm up
• Graphic 15 – device test
• Graphic 16 – alarm
• Graphic 17 – silencing the CO alarm warning
• Graphic 19 – alarm memory
• Graphic 20 – a) blocked device, b) reset blocked device
• Graphic 21 – alarm faults
Table 1 Symbol description
Carbon monoxide warning Humidity
Five years warranty Information
Waste Electrical and Electronic Equipment
(WEE) - European Directive (2012/19/EU)
Installation
Product type Maintenance
Battery life Warning
Temperature Danger to life
To Next Page
