Bosch DIVAR AN 5000 User Guide

CVBS: 1 Vpp, 75 ohm, BNC
Resolution (MON.B) CVBS (PAL): 704x576
CVBS (NTSC): 704x480
Audio
Inputs 4-ch RCA (for 4/8/16 channel), 200 to
3000 mV, 10 kOhm (RCA)
Output Mono RCA, 200 to 3000 mV, 5 kOhm (RCA)
MIC input Mono talk input RCA, 200 to 3000 mV,
10 kOhm (RCA)
Compression G.711A
Sample rate 8 kHz per channel
Bit rate 8-bit
Control
RS485 PTZ control port
Output signals according to RS485, max.
signal voltage -5 to +5 V
RS232 PTZ control port interface
Output signals according to EIA/TIA-232-F,
max input voltage ±10 V
Supported protocols Pelco P and D (over RS-485)
Bosch OSRD (over RS-485 or RS-232)
Alarms
Inputs 16 inputs configurable NO/NC, max. input
voltage 5 VDC
Outputs 5 relay outputs, configurable NO/NC, plus
one controllable 12 VDC port
Relay Max. rated, 30 VDC, 2 A continuous or
125 VAC, 1 A (activated)
Connectors
Video inputs 4, 8 or 16 BNC
Video outputs (loop
through)
4 or 8 BNC (for 4 and 8 channel units)
1 x 25-pin D-type for 16 channel unit
(connector cable supplied)
Monitor outputs 1 VGA D-SUB
1 HDMI
2 channel BNC (CVBS)
Alarm inputs 16 screw terminal inputs, cable diameter
AWG26‑16 (0.13–1.5 mm)
Alarm outputs 5 screw terminal outputs, cable diameter
AWG26‑16 (0.13–1.5 mm)
1 controllable 12 VDC screw terminal output
Audio inputs 4 RCA
Audio outputs 1 RCA
Audio bidirectional
(MIC)
1 RCA for talk input or output
Ethernet RJ45, 10/100/1000Base-T according to
IEEE802.3
Intuikey keyboard
(KBD Digital or
KBD Universal)
Conforms to RS485, max. signal voltage
±12 V, power supply to keyboard 11 to
12.6 VDC at max. 400 mA
RS485 Screw terminal output
RS232 DB9 male, 9-pin D-connector
e-SATA e-SATA connector for backup device
USB 2.0 One front and one rear USB connector for
mouse or USB memory device
+12 VDC External power input
Video recording
Recording
Speed Max. 30 IPS per channel (NTSC),
configurable
Max. 25 IPS per channel (PAL), configurable
Mode Manual, motion detection, scheduled, alarm
Network control
View alarm External, motion detection, system alarms
and video loss
Audio Bidirectional (audio input and output
connected via device)
PC software Bosch Video Client
Playback
Multi-channel Simultaneous 1/4/9/16 channels
Mode Frame-by-frame, slow play, fast play,
reverse
Search Time, channel, type, smart
Network Bosch Video Client or Web Client software
Alarm Handling
Motion detection Detection zones: 396 (PAL) / 330 (NTSC)
Video loss External alarm and screen prompt
Storage
Internal 4 SATA HDD or 2 HDD + 1 DVD (R/RW)
Max. capacity per HDD: 3 TB
Max. supported speed per HDD: 6 Gb/s
External e-SATA connection:
Max. 4 HDD
Max. capacity per HDD: 3 TB
Max. supported speed per HDD: 6 Gb/s
Exporting
DVD (optional) Built-in DVD+R/RW writer
4 | DIVAR AN 5000

Bosch DIVAR AN 5000 Specifications

General

Motion sensor	Yes
Total storage capacity	2000 GB
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Compatible operating systems	Windows XP, Windows Vista, Windows 7.
Playback resolutions supported	960x576, 960x480, 704x576, 704x480, 704x288, 704x240, 352x288, 352x240, 176x144, 176x120
Audio input	4
BNC input ports	16
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
HDD interface	Serial ATA
Maximum HDD capacity	3000 GB
Power requirements	100-240VAC 50-60Hz
Optical drive included	No
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 93 %

Weight and Dimensions

Dimensions (WxDxH)	440 x 420 x 70 mm
