English–1
1 609 929 C79 • (01.10) T
≈
* Dependent on the size, depth and type of metal as well as the material and
condition of the wall (e.g. moisture)
1 “Allowable Drilling Depth” function
2 Green “Drilling Possible” LED indicator
3 Red “Do not Drill” LED indicator
4 Display
5 Handle area with brief operating instructions
6 Battery compartment cover
7 “Search” function
8 Rotary switch
9 Marking stamp
10 On/calibration button on/cal
11 Stamping ring
12 Protective bag
Display Elements
a Measured value of the drilling depth measurement
b Bar indicator for Metal detection and drilling depth measurement
c Calibration indicator CAL
d Indicator for voltage carrying wiring in the measurement area
e Measuring unit in mm for the drilling depth measurement
f Battery indicator
The unit is intended for the detection of metal (e.g. reinforcing iron)
and mains wiring in ceilings and walls.
Product Specifications
Digital Metal Detector DMO 10 E
Order number 0 603 096 601
Maximum detection depth*
Steel to approx.
Copper to approx.
50 mm
30 mm
Automatic switch-off after approx. 75 s
Operating temperature –5 °C ... +50 °C
Storage temperature – 20 °C ... +85 °C
Battery 9 V DC 6LR 61
Weight (with battery) approx. 350 g
Product Elements
Intended Use
