English - 1
1 609 929 C10 • TMS • 25.09.00
EURO • Printed in Germany • BA 1 609 929 C10 • DUS 20 plus • GB • OSW
09/00
1 Pushbutton “Measuring operation” (length, surface,
volume)
2 Pushbutton “Measure”
3 Push button “on/off”
4 LCD Display
5 Push button “Memory recall” (MR)
6 Pushbutton “Add to memory” (M+)
7 Pushbutton “Delete” (C/MC)
8 Ultrasonic emergence-opening
9 Laser emergence-opening
10 Battery compartment cover
Working safely with this machine is possi-
ble only when the operating and safety in-
formation are read completely and the in-
structions contained therein are strictly
followed.
Laser radiation of laser class 2.
630 - 675 nm, < 1,5 mW (α = 25 mrad)
according to EN 60825 - 1:1997
Do not look into the laser beam.
Tool Specifications
Digital Ultrasonic
Measuring Tool
DUS 20 plus
Part number 0 603 096 202
Measuring range 0.6...20 m
Measuring accuracy
(+10 up to +40 °C)
(-5 up to +50 °C)
± 0.5 %
± 1 %
Smallest unit of measurement 1 cm
Ultrasonic emergence-angle
approx.
± 5°
Battery 9 V, alkaline-manganese,
6LR61
Laser class 2
Temperature range for
operation
-5...+50 °C
Temperature range for
storage
-20...+85 °C
Machine Elements
For Your Safety
2
