Air Temperature Rise/Fall | 33EP Series
8733953041 (2019/01)
EP Series
AIR TEMPERATURE RISE/FALL
Entering
Fluid
Temp° F
COOLING HEATING
Entering Air Temp° F Air Temp Drop ° F Entering Air Temp ° F Air Temp Rise ° F
30
60 15.9-23.5
70 13.5-22.9
80 14.8-22.4
40
75/63 20.6-25.0 60 18.5-26.7
80/67 21.6-25.6 70 17.9-26
85/71 22.5-26.2 80 17.2-25.5
50
75/63 20.3-24.4 60 21.3-30
80/67 20.6-24.4 70 23.3-33
85/71 21.5-25.2 80 22.5-32.3
60
75/63 19.0-23.2 60 27-37.6
80/67 20.2-23.8 70 26.1-37.1
85/71 20.8-24.5 80 25.2-36.2
70
75/63 18.5-22.5 60 30-41.7
80/67 19.3-23.2 70 29-40.8
85/71 20.5-23.9 80 28-39.9
80
75/63 18.8-22.2
80/67 19.1-23
85/71 20.3-23.6
85
75/63 18.8-22.2
80/67 19.1-23
85/71 20.3-23.6
90
75/63 19-21.8
80/67 18.9-22.7
85/71 20-23.3
100
75/63 17.2-21.3
80/67 18.4-22.1
85/71 19.5-22.7
110
75/63 16-20.7
80/67 17.1-21.4
85/71 18.2-22.2
This chart shows approximate air temperatures rise/fall for a unit in good repair. The values shown are meant as a guide only
and should not be used to estimate system charge. This chart assumes rated flow air and rated water flow. Heating data at
entering fluid temperatures below 50° assumes the use of antifreeze. as a result of continuing research and development,
specifications are subject to change without notice.
