page headingDust Collection
Attaching a Vacuum Cleaner
(Fig. 8)
Dust collection can also be achieved by attach-
ing the tool to a vacuum cleaner / dust extractor,
hose and adapter, if necessary (all sold sepa-
rately).
1. Attach the hose to the vacuum cleaner / dust
extractor.
2. Attach the hose to the tool’s Dust Port 22 in
one of the following ways (Fig. 8):
– Bosch VH-series hoses - The VX120 hose
adapter is required (included with VH-
series hoses).
– Other 35mm and 22mm hoses, such as
the Bosch VAC-series hoses - Connect
hose directly to the tool.
– Common 1-1/4” or 1-1/2” hoses - The
Bosch VAC002 or VAC024 adapter is re-
quired.
(22)
Fig. 8
Bosch VH
Series Hose
1-1/4” or
1-1/2” Hose
Bosch VAC
Series Hose
VAC002
VAC024
VX120
