page headingGetting to Know Your Product
(2)
(16)
(10)
(15)
(9)
(14)
(13)
(1)
(7)
(6)
(4)
(3)
(5)
(8)
(11)
(12)
(12) (12)
(17)
1 On/Off Button Switch
2 Dust Bag Assembly
3 Battery Pack Release Button
4 Battery Pack
5 Variable Speed Dial
6 Battery Charge Indicator Button
7 Battery Charge Indicator
8 Pivoting Feet
Cordless Orbit Sander
Fig. 1
9 Base Mounting Recess
10 Quarter (1/4) Sheet Base Plate
11 Quarter (1/4) Sheet Backing Pad
12 Base Plate Screws (x4)
13 Rectangular (1/3) Sheet Base Plate
14 Rectangular (1/3) Sheet Backing Pad
15 Detail Sheet Base Plate
16 Detail Sheet Backing Pad
17 Gripping Surface (Insulated)
