English | 7
Bosch Power Tools 1 609 92A 2WC | (10.11.16)
Technical Data
Assembly
Before any work on the machine itself, pull the mains
plug.
Replacing/Inserting the Saw Blade
When mounting the saw blade, wear protective gloves.
Danger of injury when touching the saw blade.
Selecting a Saw Blade
An overview of recommended saw blades can be found at the
end of these instructions. Use only T-shank saw blades. The
saw blade should not be longer than required for the intended
cut.
Use a thin saw blade for narrow curve cuts.
Inserting/Replacing the Saw Blade (see figure A)
Loosen the screws 12 until the assembly plate with the guide
roller 5 can be moved toward the rear.
Push the assembly plate with the guide roller 5 forwards until
it faces against the back of the saw blade and tighten the
screws 12 again.
Check the tight seating of the saw blade. A loose saw
blade can fall out and lead to injuries.
For removal of the saw blade, proceed in reverse order.
Splinter Guard (see figure B)
The splinter guard 11 (accessory) can prevent fraying of the
surface while sawing wood. The splinter guard can only be
used for certain saw blade types and only for cutting angles of
0°. When sawing with the splinter guard, the base plate 4
must not be moved back for cuts that are close to the edge.
Press the splinter guard 11 from the bottom into the base
plate 4.
Dust/Chip Extraction
Dust from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one’s health. Touching or breathing-in the dust can cause
allergic reactions and/or lead to respiratory infections of
the user or bystanders.
Certain dust, such as oak or beech dust, is considered car-
cinogenic, especially in connection with wood-treatment
additives (chromate, wood preservative). Materials con-
taining asbestos may only be worked by specialists.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the
materials to be worked.
Prevent dust accumulation at the workplace. Dust can
easily ignite.
Operation
Operating Modes
Before any work on the machine itself, pull the mains
plug.
Adjusting the Cutting Angle (see figure C)
The base plate 4 can be swivelled by 45° to the left or right for
mitre cuts.
Loosen the screws 12 and lightly push the base plate 4 in the
direction of the saw blade 6.
Jigsaw GST 65
GST 65 B
GST 65 E
GST 65 BE
Article number
3 601 E09 1.. 3 601 E09 2..
Stroke rate control
–
Rated power input W400400
Output power
W230230
Stroke rate at no load n
0
min
–1
3100 500–3100
Stroke mm 18 18
Cutting capacity, max.
– in wood
–in aluminium
– in non-alloy steel
mm
mm
mm
65
12
3
65
12
3
Bevel cuts (left/right), max.
°4545
Weight according to EPTA-Procedure 01:2014
kg 1.7 1.7
Protection class /II /II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Insert the screwdriver 9 from above into the stroke rod 10
and turn approx. 3–4 turns in anticlockwise direction.
Insert the saw blade 6 lateral to the cutting direction into
the stroke rod 10.
Turn the saw blade 6 so that the toothing faces toward the
cutting direction. Pull the saw blade 6 a little downward
until it engages.
Insert the screwdriver 9 from above into the stroke rod 10
and turn in clockwise direction until the saw blade 6 is
locked.
