VG4 Modular Camera Series Installing Roof Parapet and Pipe Mounts | en 65
Bosch Security Systems, Inc. Installation Manual F.01U.216.010 | 8.0 | 2011.02
5. Hold the housing firmly in position and alternately tighten the two (2) 5-mm Allen head
mounting screws from above to a torque value of 10-12 N-m (90-105 in.-lbs).
6. Rotate the arm to swing the AutoDome out from the roof and into position, if installing a
Parapet Roof Mount.
7. Tighten the three (3) 10-mm (3/8-inch) stainless steel hex bolts on the bracket to lock
the Parapet Arm in position. See Figure 3.15, Page 64, for an illustration.
3.10 Make Connections in the Power Supply Box
The following procedure references Figure 3.6, Page 56 to locate the various connectors in the
box and to make the proper connections.
1. Attach the earth ground wire to the grounding screw on the left side of the box.
2. Connect the 24 VAC to Dome plug, installed previously, to its mating connector P107 on
the right side of the box.
3. Connect the 115/230 VAC, 3-pin Power-in plug, installed previously, to its matting
connector P101 on the left side of the box.
3.10.1 Connections for Fiber Optic Models
The following procedure references Figure 3.6, Page 56.
1. If installing a Fiber Optic model, attach the incoming ST fiber plug to its mating
connector on the Fiber Optic Module in the power box.
2. Connect the video BNC connector from the dome to the Fiber Optic Module BNC
connector.
3. Connect the six (6) control plugs from the dome, installed previously, to the P106 control
I/O connector in the Power Supply Box.
CAUTION!
If you feel any resistance when rotating the dome housing or when engaging the connector,
stop immediately and start over.
CAUTION!
You must tighten the two mounting screws to a minimum torque of 10-12 N-m (90-105 in.-lbs)
to ensure a proper seal between the arm and the housing.
CAUTION!
Do not over tighten the bolts. The maximum torque is 34 N-m (25 ft-lb).
NOTICE! A BNC barrel connector (not supplied) is required to connect the male BNC of the
dome to the male BNC connector of the Fiber Optic Module.
