10.1 Dimensions of the embedded automation computer
The devices can be mounted on the top-hat rail. For the corresponding dimen-
sions, please refer to the following figures:
Fig. 10-1: Mounting dimensions for device variant NA, top-hat rail mounting
12/29
Mounting, assembly and electrical installation
IndraControl PR21 Embedded Automa-
tion Computer
Bosch Rexroth AG R911389662_Edition 02
