Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Jigsaw
Model number JS260
NOTE: For tool specifications refer to the nameplate on your tool.
"LOCK-ON" BUTTON
TRIGGER SWITCH
ALLEN WRENCH
5 MM
HEAVY-DUTY STEEL
FOOTPLATE
BLADE ROLLER
GUIDE
BLADE ORBIT
SELECTOR LEVER
VENTILATION
OPENINGS
VARIABLE
SPEED DIAL
FIG. 1
