Bosch JS572E - Product Overview and Specifications

-7-
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
P
ro
fe
s
s
i
o
n
a
l
INTAKE
VENTILATION
OPENINGS
VARIABLE SPEED CONTROLLED
TRIGGER SWITCH (Model JS572E only)
FOOTPLATE
DUST BLOWER
LEVER
BLADE ORBIT SELECTOR LEVER
BLADE CHANGE
LEVER
PRECISION CONTROL II -
DOUBLE ROLLER GUIDE
“LOCK-ON” BUTTON
(Model JS572E only)
FINGER
GUARD
VARIABLE SPEED DIAL
(Model JS572E)
WORK LIGHT
ON/OFF SWITCH
INSULATED
GRIPPING
SURFACES
INSULATED
GRIPPING
SURFACES
FIG. 1a
JS572E Jig Saw
