Bosch Diagnostics|1 689 979 987 2006-09-29
16 | KTS 530 / KTS 540 / KTS 570 | Description of unit
2. D escription of unit
2.1 A pplication
KTS 530, KTS 540 and KTS 570 (hereinafter referred to as
KTS modules) are modules for controller diagnosis. The
functionality differences are shown in the following table:
F unction KTS 530 KTS 540 KTS 570
Controller diagnosis
X X X
1 channel multimeter X X
X
2 channel multimeter
– – X
2 channel oscilloscope
– –
X
2 channel diagno-
sis oscilloscope
– –
X
Bluetooth wireless connection
– X X
USB connection X X X
KTS modules can perform the following functions with
ESI[tronic]:
C ontroller diagnosis, with e.g.
Read error memory
Display actual values
Initiate actuators
Use of other controller-specific functions
M ultimeter measurements for
V oltage measurement
Resistance measurement
Current measurement (only with special
accessory current measuring clips or shunt)
2 channel oscilloscope for determining
measurement values (K T S 5 70 only ) .
2 channel diagnosis oscilloscope for testing the
controller diagnosis interface (K T S 5 70 only ) .
R
I
I
I
I
R
I
I
I
R
R
2.2 R eq uirements
2.2.1 H ardw are
PC/Laptop with at least one free USBinterface.
KTS modules can be used with the following Bosch
products:
Emissions System Analysis
(*)
FSA 740
BEA 810, BEA 840, BEA 850
(*)
(*)
D e p e n d in g o n th e s o ftw a re v e rs io n .
2.2.2 Operating system
Operating system U SB Bluetooth
WIN XP
X X
2.2.3 Softw are
Operation of the KTS modules requires the installation
and enabling of software ESI[tronic]-DV D 2006/1 and
ESI[tronic]-CD 2006/3 U (blue U ) on the PC/Laptop.
Extra costs apply in this case.
R
R
R
