Bosch Security Systems | 2003-09 | 3922 988 99482en
Plena Universal Pre-amplifier | Installation and Operating Manual | en | 11
3 Installation in rack
Figure 3.1
The universal pre-amplifier is delivered for table-top use, but you can mount it in a 19" rack. If you mount the
pre-amplifier in a rack, you must:
• use the mounting brackets delivered with the unit.
• remove the 4 feet from the bottom of the unit. (Without the feet the unit is 2U high).
Installation in rack
1/Line
0d
B
-
6dB
-
2
0dB
P
o
w
er
2/L
i
n
e
3
/Line
4/L
i
n
e
2
3
4
5
M
a
st
e
r
Sel
ec
t
Mas
t
er
Pl
e
na
U
n
iversal P
re-
ampli
fier
