EN | 90 Bosch Security Systems | December 13, 2005
•The LTC 8506/00 cable (used to connect the Allegiant's console port to an
external PC) uses the following pin-outs:
•For reference, a cable to connect the Allegiant's printer port to an external serial
printer would use the following pin-outs:
9-Pin Male
(Console)
Allegiant Designation 9-Pin Female (PC Side)
1Chassis GND None
2 Receive Data 3
3 Transmit Data 2
4 CTS 1
5 RTS 8
6 No Connection None
7 Data GND 5
8 No connection None
9 No connection None
(pins 4 & 6 jumpered)
(pins 1 & 7 jumpered)
9-Pin Male Printer
(Printer)
Allegiant Designation 25-Pin Female
(Printer Side)
1 Chassis GND 1
2 Receive Data 2
3 Transmit Data 3
4 CTS 4,8
5 RTS 5
6 No Connection None
7 Data GND 7
8 No connection None
9 No connection None
(pins 6 & 20 jumpered)
