EN | 88 Bosch Security Systems | December 13, 2005

23 Main Bay Rear Panel Connector Pin-outs

and Cable Pin-out

Console Port RS-232 Pin-outs

Pin # Designation

1CHASSIS GND

2Rx

3Tx

4CTS

5RTS

6NO CONNECTION

7DATA GND

8NO CONNECTION

9NO CONNECTION

Alarm Port RS-232 Pin-outs

Pin # Designation

1RTS

2Tx

3CHASSIS GND

4DATA GND

5DATA GND

6Rx

7CTS

812 VAC

912 VAC

Keyboard RS-485 Ports

Pin # Designation

112 VAC

2GND

3-DATA

4+DATA

5GND

612 VAC

Printer Port RS-232 Pin-outs

Pin # Designation

1CHASSIS GND

2Rx

3Tx

4CTS

5RTS

6NO CONNECTION

7DATA GND

8NO CONNECTION

9NO CONNECTION
