LTC 8600 | LTC 8800 Series en | 33
F.01U.127.393 | 2.0 | 2009.03 Instruction Manual Bosch Security Systems, Inc.
8.6.3 LTC 8802 Series Monitor Expansion Bay Data Connections
The LTC 8802 Series Monitor Expansion Bay is supplied with a 1 m (3 ft) data com-
munication interconnect cable. Install this cable between the Comm1 port on the
LTC 8801 Series Main CPU bay, and the Comm1 port on the LTC 8802 Series Moni-
tor Expansion Bay.
8.6.4 Monitor Output Video Connections
Just like camera inputs, monitor outputs on the Allegiant system are designed to be
terminated. Each monitor output expects to be connected to a 75 ohm load. This is
the regular load typically provided by a normal monitor. If a monitor output line is
“looped” through several monitors or other equipment, the system installer should
make sure that only the last unit on the line is terminated.
