6 720 862 440 (2016/04) Heat Pump Mini VRF Outdoor Unit
2 |
1
2
3
4
Fig. 1
1
air outlet
3
Bracket
2
air inlet
4
Connection for refrigerant pipework
NOTE
All the pictures in this manual are for explanation purposes only. They may be slightly different from the air conditioning unit you have purchased (dependent
on model).
