English–1
1 609 929 E16 • (03.05) T
* Outside of the operating temperature, the display can become black.
Please observe the order number of your unit. The trade names of the individual units may vary.
Measured values determined according to EN 50 144.
Typically the A-weighted sound pressure level of the
product is less than 70 dB(A).
1
Nozzle
2
Heat protection
3
PHG 500-2/PHG 600-3:
On-off switch/Air flow and temperature regulator
3
PHG 630 DCE:
On-off switch/Air flow regulator
4
Button for setting the temperature
(PHG 630 DCE)
5
Display (PHG 630 DCE)
6
Wide nozzle*
7
Glass protection nozzle*
8
Reflector nozzle*
9
Welding rod*
10
Welding shoe*
11
Reduction nozzle*
12
Heat-shrinkable tubing*
* Not all the accessories illustrated or described are in-
cluded in standard delivery.
The unit is intended for the forming and welding of
plastic, removal of paint and the warming of heat-
shrinkable tubing.
It is also suitable for soldering and tinning, loosening of
adhesive joints and the defrosting of water lines.
Working safely with this unit is pos-
sible only when the operating and
safety information are read com-
pletely and the instructions con-
tained therein are strictly followed.
The workplace should be well ventilat-
ed. Gases and vapours that occur are
frequently detrimental to health.
■
The unit must not be damp and must also not be
operated in damp surroundings.
■
Before each use of the unit, check the cable and
plug. If damage is detected, do not use the unit.
Have repairs performed only by a qualified techni-
cian. Never open the unit yourself.
■
Connect units that are used in the open via a re-
sidual current device (RCD) with an actuating cur-
rent of 30 mA maximum. Do not operate the unit in
rain or moisture.
■
Do not carry or hang up the unit by the cable.
■
Always direct the cable to the rear away from the
unit.
Product Specifications
Hot Air Blower PHG 500-2 PHG 600-3 PHG 630 DCE
Order number
0 603 29A 0.. 0 603 29B 0.. 0 603 29C 7..
Power consumption max. [W] 1600 1800 2000
Air flow approx. [l/min] 240/450 250/350/500 150/300/500
Temperature at nozzle outlet approx. [°C] 300/500 50/400/600 50 ... 630
Temperature measuring accuracy
at the nozzle outlet
on the display
±10 %
–
±10 %
–
±10 %
±5 %
Display operating temperature* [°C] – – 0 ... +50
Weight (without accessories) approx. [kg] 0.75 0.8 0.9
Protection class /
II
/
II
/
II
Noise Information
Product Elements
Intended Use
For Your Safety
