18 | English
1 609 929 W68 | (3.3.10) Bosch Power Tools
Product Features
The numbering of the product features refers to
the illustration of the sawing station on the
graphics pages.
PLS 300
1 Base unit
2 Scale for mitre angle (horizontal)
3 Locking knob for height adjustment
4 Guide rail with sawing slot
5 Side stops of the guide rail
6 Support extension
7 Additional support
8 Bridge
9 End stop for bevel cuts
10 Locking lever of the guide rail
11 Alignment mark
12 Locking knob for various mitre angles
(horizontal)
13 Angle indicator (horizontal)
PTC 1*
14 Tile cutter
15 Stop with scale
16 Break-off cones
* only in combination with PLS 300 Set
Technical Data
f Only use the saw blades recommended by
Bosch (see page 223). When using saw
blades that are too thin, danger is given that
the cut runs out of centre.
Sawing station PLS 300 PLS 300 Set
(PLS 300 + PTC 1)
Article number
3 603 M04 0.. 3 603 M04 1..
Sawing
– Max. cutting length for crossway cuts (90°)
– Max. cutting height
– Mitre/Bevel Angle
Horizontal
Vertical
mm
mm
°
°
315
25
± 45
± 45
315
25
± 45
± 45
Cutting tiles
– Max. cutting length for crossway cuts (90°)
– Max. cutting height
– Mitre/Bevel Angle
Horizontal
mm
mm
°
–
–
–
340
10
± 45
Weight according to EPTA-Procedure 01/2003
kg 3.4 3.4 + 0.2
Dimension of suitable saw blades
Max. overall length
mm 100
Max. toothed length
mm 76
