English | 23
Intended Use
The measuring tool is intended for measuring distances, lengths, heights and clearances,
and for calculating areas and volumes.
The measuring tool is suitable for indoor and outdoor use.
Product features
The numbering of the product features shown refers to the illustration of the measuring
tool on the graphic page.
(1)
Display
(2)
Measuring button [ ]
(3) Minus button [−]
(4) Function button [Func]
(5)
On/off button [ ]
(6) Plus button [+]
(7)
Battery compartment cover
(8)
Locking mechanism of the battery compartment cover
(9)
Serial number
(10)
Laser warning label
(11)
Reception lens
(12)
Laser beam output
(13)
Laser target plate
A)
(14)
Laser viewing glasses
A)
A)
Accessories shown or described are not included with the product as standard. You can
find the complete selection of accessories in our accessories range.
Display elements
(a)
Laser switched on
(b)
Temperature warning
(c)
Battery warning
(d)
Value
(e)
Unit of measurement
(f)
Measuring functions
Length measurement
Bosch Power Tools 1 609 92A 5DX | (27.01.2020)
