English–3
2 609 932 333 • 29.9.04
Machine Elements
The numbering of the machine elements refers to the
illustration of the machine on the graphics page.
1 Lock-on button for On/Off switch
2 On/Off switch
3 Vacuum hose*
4 Vacuum connection
5 Saw blade storage*
6 Base plate
7 Switch for sawdust blowing device
8 Scale for mitre angle
9 Guide roller
10 SDS clamping lever for saw blade release
11 Saw blade*
12 Cutting line mark
13 Contact protector
14 Stroke rod
15 Dust cover for vacuuming*
16 Splinter guard*
17 Screw
18 Holder for guide roller
19 Lead for the parallel guide
20 Locking screw for parallel guide*
21 Parallel guide with circle cutter*
22 Centring tip of the parallel guide*
*Not all of the accessories illustrated or described are
included as standard delivery.
Technical Data
The values given are valid for nominal voltages [U] of 230/240 V. For lower voltage and models for specific coun-
tries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines
may vary.
Declaration of Conformity
We declare under our sole responsibility that this prod-
uct is in conformity with the following standards or
standardization documents:
EN 60745 according to the provisions of the directives
89/336/EEC, 98/37/EC.
Robert Bosch GmbH, Geschäftsbereich Elektrowerkzeuge
Assembly
Dust/Chip Extraction
Take safety measures when dusts can be pro-
duced during working that are detrimental to
one’s health, inflammable or explosive. Example:
Some dusts are regarded as carcinogenic. Use suita-
ble dust/chip extraction and wear a dust respirator.
Keep your workplace clean. Blends of materials are
particularly dangerous. Dust from light alloys can burn
or explode.
Jigsaw PST 600 PST 650 PST 680 E
Article number 3 603 C92 02. 3 603 C92 0.. 3 603 C92 1..
Stroke rate control – – !
Rated power input W 470 500 500
Stroke rate at no load spm 3100 3100 500–3100
Stroke mm 22 22 22
Cutting capacity, max.
in wood mm 60 65 68
in aluminium mm 6 8 10
in non-alloy steel mm 3 3 4
Bevel cuts (left/right), max. ° 45 45 45
Weight according to EPTA-Procedure 01/2003 kg 1.7 1.7 1.7
Protection class / II / II / II
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
OBJ_BUCH-2 609 932 333-002.book Seite 3 Mittwoch, 29. September 2004 10:23 10
