6/8
Bosch Rexroth Corp.
Industrial Hydraulics
RA 17 041-DT4SM/06.09Service Manual for CDT4-CDG4
Spare Parts
Bore Ø (inches) M T * F * V *
1.500 R978006830 R978006850 R978006860 R978006840
2.000 R978006831 R978006851 R978006861 R978006841
2.500 R978006832 R978006852 R978006862 R978006842
3.250 R978006833 R978006853 R978006863 R978006843
4.000 R978006834 R978006854 R978006864 R978006844
5.000 R978006835 R978006855 R978006865 R978006845
6.000 R978006836 R978006856 R978006866 R978006846
7.000 R978006837 R978006857 R978006867 R978006847
8.000 R978006838 R978006858 R978006868 R978006848
Rod Ø (inches) M T * F * V *
0.625 R978006773 R978006801 R978006815 R978006787
1.000 (1.500" bore) R978006774 R978006802 R978006816 R978006788
1.000 (2.000"-2.500" bore) R978006775 R978006803 R978006817 R978006789
1.375 (2.000" bore) R978006776 R978006804 R978006818 R978006790
1.375 (2.500"-3.250" bore) R978006777 R978006805 R978006819 R978006791
1.750 R978006778 R978006806 R978006820 R978006792
2.000 R978006779 R978006807 R978006821 R978006793
2.500 R978006780 R978006808 R978006822 R978006794
3.000 R978006781 R978006809 R978006823 R978006795
3.500 R978006782 R978006810 R978006824 R978006796
4.000 R978006783 R978006811 R978006825 R978006797
4.500 R978006784 R978006812 R978006826 R978006798
5.000 R978006785 R978006813 R978006827 R978006799
5.500 R978006786 R978006814 R978006828 R978006800
Piston and Tube Seal Kits (Items 19e, f, g, h) ~
(Z10 Series prior to November 1, 2006)
Rod Cartridge Seal Kits w/Rod Bearing (Items 19a, b, c, d, Item 16) †§
(Z10 Series prior to November 1, 2006)
M = Polyurethane seal system (standard)
T = Seal system for low frction applicatios (available)
F = Standard seal system for HFC (water glycol) (available)
V = Seal system for (phosphate ester) (available)
Note:
* = not recommended for load holding applications
§ = CGT4 (double-rod) version requires two Rod Cartridge Kits
~ Piston/Tube Seal Kits include: one (1) double-acting piston
seal;
two (2) wear bands; two (2) o-rings and two (2) back-up rings
† Rod Cartridge Seal Kits include: one (1) double-lip wiper
set;
one (1) u-cup rod seal; one (1) rod bearing; one (1) back-up
ring, one (1) o-ring
Cushion Valve (Item 17)
Bore Size** M, T, F V
1-1/2", 2", 2-1/2" R433015236 R978006424
3-1/4", 4", 5" R433016568 R978006436
6", 8" R433023258 R978006437
Courtesy of CMA/Flodyne/Hydradyne ▪ Motion Control ▪ Hydraulic ▪ Pneumatic ▪ Electrical ▪ Mechanical ▪ (800) 426-5480 ▪ www.cmafh.com
